Transfer Capacity (TC) Siemens PSS SINCAL Optimization and Planning Modules

Transfer Capacity (TC)

The calculation of the transfer capacity (TC) in PSS®SINCAL consists of a series of load-flow calculations. In each individual load-flow calculation the active power of the incoming supplies varies in order to ensure a transfer between two network areas.

The results include all relevant data (TTC, NTC, TRM etc.) for the transfer.

The following illustration shows the most important ENTSO-E parameters for the different phases.

The system takes into consideration already predefined transfers between areas and also determines if an additional capacity can be transferred.

Optimization and Planning Modules

PSS®SINCAL Optimization and Planning Modules

Optimize the flow and the quality of power in your network and determine the best possible structure including Optimal Branching, Compensation Optimization, Volt/Var Optimization and more.

PSS®SINCAL supports your entire engineering workflow

For over 20 years, PSS®SINCAL has enabled engineers to tackle different challenges of the changing distribution, transmission, and industrial power systems, including maintaining high reliability of supply and efficiently integrating Distributed Energy Resources. With the modular platform of PSS®SINCAL, power system planning and operation engineers are supported with their entire workflow from the initial data import and network modeling (considering past, current and future conditions), to basic and extended calculations, all the way to extensive protection simulations and analysis as well as other methods in time and frequency domains.
